| Configuration Parameters Table |
| Model/ Parameter |
2024 Model Shan 600 Single-sea t Version |
2024 Model Shan 600 Dual-seat Version |
|
| ABS | Standard front and rear | Standard front and rear | |
| ABS anti-lock braking | Standard front and rear | Standard front and rear | |
| USB charging port | Standard USB | Standard USB | |
| Launch time | 2023-09-15 | 2023-11-20 | |
| Main fuel tank capacity (L) | 16 | 16 | |
| Instrument panel | 3.6-inch Circular TFT | 3.6-inch Circular TFT | |
| Transmission mode | Belt drive | Belt drive | |
| Fuel supply method | Electronic fuel injection | Electronic fuel injection | |
| Cooling method | Water-cooled | Water-cooled | |
| Front brake system | 300mm Dual Discs with Radial F our-Piston Calipers |
300mm Dual Discs with Radial F our-Piston Calipers |
|
| Front suspension system | Marzocchi Inverted | Marzocchi Inverted | |
| Headlight | LED | LED | |
| Front wheel specification | 130/90-16 | 130/90-16 | |
| Hazard warning lights (hazard lights) |
Standard equipment | Standard equipment | |
| Reference price | 5142 USD | 5142 USD | |
| Engine | V-type Four-Cylinder Four-Stro ke Water-Cooled·560cc |
V-type Four-Cylinder Four-Stro ke Water-Cooled·560cc |
|
| Engine stroke | Four-stroke | Four-stroke | |
| Engine model | QJ4V61MS-D | QJ4V61MS-D | |
| Number of engine cylinders | Four cylinders | Four cylinders | |
| Engine structure | V-type | V-type | |
| Transmission | International 6-speed | International 6-speed | |
| Transmission type | International 6-speed | International 6-speed | |
| Available colors | Charcoal Grey, Day and Night B lack, Blackcurrant Purple, Sat in Silver |
Charcoal Grey, Day and Night B lack, Blackcurrant Purple, Sat in Silver |
|
| Rear brake system | 260mm Single Disc with Single- Piston Floating Caliper |
260mm Single Disc with Single- Piston Floating Caliper |
|
| Rear suspension system | Marzocchi Spring Tube Damping | Marzocchi Spring Tube Damping | |
| Rear light | LED | LED | |
| Rear wheel specification | 180/65-16 | 180/65-16 | |
| Brand | QJMOTOR | QJMOTOR | |
| Navigation projection function | Standard equipment | Standard equipment | |
| Seat height (mm) | 720 | 720 | |
| Mobile phone connection functi on (Bluetooth/WIFI, etc.) |
Standard equipment | Standard equipment | |
| Gear display | Standard equipment | Standard equipment | |
| Displacement (cc) | 560 | 560 | |
| Curb weight (kg) | 219 | 221 | |
| Maximum power (kW) | 50 | 50 | |
| Maximum power/speed (kW/rpm) | 50/10500 | 50/10500 | |
| Maximum power speed (rpm) | 10500 | 10500 | |
| Maximum torque (N·m) | 54 | 54 | |
| Maximum torque/speed (N·m/rpm) | 54/8000 | 54/8000 | |
| Maximum torque speed (rpm) | 8000 | 8000 | |
| Maximum horsepower (Ps) | 68.0 | 68.0 | |
| Maximum horsepower (ps) | 68.0 | 68.0 | |
| Maximum speed (km/h) | 178 | 178 | |
| Mode selection | Sport Mode Normal Mode | Sport Mode Normal Mode | |
| Fuel tank capacity (L) | 16 | 16 | |
| Throttle configuration | Dual-cable throttle | Dual-cable throttle | |
| Slipper clutch | Standard equipment | Standard equipment | |
| Fuel type | Gasoline | Gasoline | |
| Traction control system | Standard equipment | Standard equipment | |
| Clutch | Wet multi-plate slipper clutch | Wet multi-plate slipper clutch | |
| Exact displacement (cc) | 561 | 561 | |
| Tire pressure monitoring | Standard equipment | Standard equipment | |
| Model | Cruise | Cruise | |
| Handlebar | Integral | Integral | |
| Frame type | Cradle Type | Cradle Type | |
| Turn signal | LED | LED | |
| Tire brand | Cheng Shin (品牌名，通常直接用拼音) | Cheng Shin (品牌名，通常直接用拼音) | |
| Tire type | Vacuum tire | Vacuum tire | |
| Rim | Aluminum alloy cast type | Aluminum alloy cast type | |
| Wheelbase (mm) | 1580 | 1580 | |
| Intake form | Naturally aspirated | Naturally aspirated | |
| Valve train structure | DOHC four valves per cylinder | DOHC four valves per cylinder | |
| Length x width x height (mm) | 2280x820x1115 | 2280x820x1115 |
