| Configuration Parameters Table |
| Model/ Parameter |
2023 CBR650R | 2024 CBR650R E-Clutch | |
| ABS | Standard front and rear | Standard front and rear | |
| ABS anti-lock braking | Standard front and rear | Standard front and rear | |
| Launch time | 2023-11-30 | 2024-09-13 | |
| Main fuel tank capacity (L) | 15.4 | 15.4 | |
| Instrument panel | Full-digital monochrome LCD in strument |
- | |
| Transmission mode | Chain drive | Chain drive | |
| Fuel supply method | Electronic fuel injection | Electronic fuel injection | |
| Cooling method | Water-cooled | Water-cooled | |
| Front brake system | Dual 310mm floating brake disc s with radial opposed calipers |
- | |
| Front suspension system | Showa SFF-BP | Showa SFF-BP | |
| Headlight | LED | LED | |
| Front wheel specification | 120/70-ZR17 | 120/70-ZR17 | |
| Compression ratio | 11.6:1 | 11.6:1 | |
| Reference price | 11400 USD | 11828 USD | |
| Engine | In-line four-cylinder four-str oke, water-cooled·650cc |
In-line four-cylinder four-str oke, water-cooled·650cc |
|
| Engine stroke | Four-stroke | Four-stroke | |
| Engine model | RH01E | RH15E | |
| Number of engine cylinders | Four cylinders | Four cylinders | |
| Engine structure | In-line | In-line | |
| Transmission | International 6-speed | International 6-speed | |
| Transmission type | International 6-speed | International 6-speed | |
| Available colors | Bianyan Red, Lava Black | Red, Black | |
| Rear brake system | 240mm single brake disc with s ingle-cylinder caliper |
- | |
| Rear suspension system | Mid-mounted monoshock | Mid-mounted monoshock | |
| Rear light | LED | LED | |
| Rear wheel specification | 180/55-ZR17 | 180/55-ZR17 | |
| Brand | Honda DREAMWING | Honda DREAMWING | |
| Official average fuel consumpt ion (L/100km) |
4.37 | 4.37 | |
| Seat height (mm) | 810 | 810 | |
| Gear display | Standard equipment | - | |
| Displacement (cc) | 650 | 650 | |
| Curb weight (kg) | 208 | 212 | |
| Maximum power (kW) | 56 | 56 | |
| Maximum power speed (rpm) | 9000 | 9000 | |
| Maximum torque (N·m) | 60 | 60 | |
| Maximum torque speed (rpm) | 8000 | 8000 | |
| Maximum horsepower (ps) | 76.1 | 76.1 | |
| Minimum ground clearance (mm) | 130 | 130 | |
| Maximum speed (km/h) | 193 | 193 | |
| Fuel tank capacity (L) | 15.4 | 15.4 | |
| Throttle configuration | Dual-cable throttle | Dual-cable throttle | |
| Slipper clutch | Standard equipment | - | |
| Fuel type | Gasoline | Gasoline | |
| Traction control system | Standard equipment | - | |
| Clutch | Wet multi-plate slipper clutch | Wet multi-plate slipper clutch | |
| Exact displacement (cc) | 649 | 649 | |
| Bore x stroke (mm) | 67x46 | 67x46 | |
| Model | Sports bike | Sports bike | |
| Handlebar | Split | Split | |
| Turn signal | LED | LED | |
| Tire brand | - | Dunlop | |
| Tire type | Vacuum tire | Vacuum tire | |
| Rim | Aluminum alloy cast type | Aluminum alloy cast type | |
| Wheelbase (mm) | 1450 | 1450 | |
| Intake form | Stamped air intake | Naturally aspirated | |
| Valve train structure | DOHC four valves per cylinder | DOHC four valves per cylinder | |
| Length x width x height (mm) | 2130x750x1150 | 2130x750x1150 | |
| Windshield | Standard non-adjustable | Standard non-adjustable |
