| Configuration Parameters Table |
| Model/ Parameter |
2024 X-ADV 750 | 2025 X-ADV 750 | |
| ABS | Standard front and rear | Standard front and rear | |
| ABS anti-lock braking | Standard front and rear | Standard front and rear | |
| Launch time | - | 2025-01-17 | |
| Main fuel tank capacity (L) | 13.2 | 13.2 | |
| Instrument panel | 5-inch TFT full-color LCD inst rument |
5-inch TFT full-color LCD inst rument |
|
| Transmission mode | Chain drive | Chain drive | |
| Fuel supply method | Electronic fuel injection | Electronic fuel injection | |
| Cooling method | Water-cooled | Water-cooled | |
| Front brake system | 296mm dual discs with opposed four-piston radial calipers |
- | |
| Front suspension system | φ41mm inverted front fork, adj ustable spring preload and reb ound damping |
φ41mm Showa inverted front for k, adjustable spring preload a nd rebound damping, stroke 120 mm |
|
| Headlight | LED | LED | |
| Front wheel specification | 120/70-R17 | 120/70-R17 | |
| Compression ratio | 10.7:1 | 10.7:1 | |
| Reference price | 18542 USD | 18542 USD | |
| Engine | In-line twin-cylinder four-str oke, water-cooled·750cc |
In-line twin-cylinder four-str oke, water-cooled·750cc |
|
| Engine stroke | Four-stroke | Four-stroke | |
| Number of engine cylinders | Twin cylinders | Twin cylinders | |
| Engine structure | In-line | In-line | |
| Transmission | DCT 6-speed automatic transmis sion |
DCT 6-speed automatic transmis sion |
|
| Transmission type | DCT 6-speed automatic transmis sion |
DCT 6-speed automatic transmis sion |
|
| Rear brake system | 240mm single disc with single- piston caliper |
- | |
| Rear suspension system | Pro-Link multi-link single sho ck absorber, adjustable preloa d |
Pro-Link multi-link single sho ck absorber, 10-stage adjustab le preload, stroke 120mm |
|
| Rear light | LED | LED | |
| Rear wheel specification | 160/60-R15 | 160/60-R15 | |
| Brand | Honda DREAMWING | Honda DREAMWING | |
| Official average fuel consumpt ion (L/100km) |
3.53 | 3.54 | |
| Cruise control | - | Standard equipment | |
| Seat height (mm) | 790 | 790 | |
| Gear display | Standard equipment | Standard equipment | |
| Displacement (cc) | 750 | 750 | |
| Curb weight (kg) | 235 | 237 | |
| Keyless start | Standard equipment | Standard equipment | |
| Maximum power (kW) | 43.1 | 43.1 | |
| Maximum power/speed (kW/rpm) | 43.1/6750 | 43.1/6750 | |
| Maximum power speed (rpm) | 6750 | 6750 | |
| Maximum torque (N·m) | 69 | 69 | |
| Maximum torque/speed (N·m/rpm) | 69/4750 | 69/4750 | |
| Maximum torque speed (rpm) | 4750 | 4750 | |
| Maximum horsepower (Ps) | 58.6 | 58.6 | |
| Maximum horsepower (ps) | 58.6 | 58.6 | |
| Minimum ground clearance (mm) | 135 | 135 | |
| Minimum turning radius (m) | - | 2.8 | |
| Mode selection | Sport mode, Standard mode, Rai n mode, Custom mode, Sand mode |
Sport mode, Standard mode, Rai n mode, Custom mode, Gravel mo de |
|
| Fuel tank capacity (L) | 13.2 | 13.2 | |
| Throttle configuration | Electronic throttle | Electronic throttle | |
| Fuel type | Gasoline | Gasoline | |
| Traction control system | Standard equipment | - | |
| Clutch | Wet multi-plate clutch | Wet multi-plate clutch | |
| Exact displacement (cc) | 745 | 745 | |
| Bore x stroke (mm) | 77x80 | 77x80 | |
| Model | Footrest | Footrest | |
| Handlebar | Variable diameter | Variable diameter | |
| Frame type | Diamond-shaped steel tube fram e |
Diamond-shaped braided frame | |
| Turn signal | LED | LED | |
| Tire type | Vacuum tire | Vacuum tire | |
| Rim | Spoked Tire | Aluminum spoke type | |
| Wheelbase (mm) | 1590 | 1580 | |
| Intake form | Naturally aspirated | Naturally aspirated | |
| Valve train structure | OHC four valves per cylinder | OHC four valves per cylinder | |
| Length x width x height (mm) | 2200x940x1380 | 2200x940x1380 | |
| Windshield | Standard equipment | Standard equipment |
