| Configuration Parameters Table |
| Model/ Parameter |
2023 F 750 GS Adventure Editio n |
2023 F 750 GS Comfort Edition | 2023 F 750 GS Sport Edition |
| ABS | Standard front and rear | Standard front and rear | Standard front and rear |
| ABS shutdown function | Standard equipment | Standard equipment | Standard equipment |
| ABS anti-lock braking | Standard front and rear | Standard front and rear | Standard front and rear |
| Main fuel tank capacity (L) | 15 | 15 | 15 |
| Transmission mode | Chain drive | Chain drive | Chain drive |
| Fuel supply method | Electronic fuel injection | Electronic fuel injection | Electronic fuel injection |
| Cooling method | Water-cooled | Water-cooled | Water-cooled |
| Forward tilt angle (°) | 63 | 63 | 63 |
| Front brake system | 305mm dual floating discs, dua l-piston floating calipers |
305mm dual floating discs, dua l-piston floating calipers |
305mm dual floating discs, dua l-piston floating calipers |
| Front suspension system | Telescopic front fork φ41mm | Telescopic front fork φ41mm | Telescopic front fork φ41mm |
| Headlight | Halogen | Halogen | Halogen |
| Front wheel specification | 110/80-R19 | 110/80-R19 | 110/80-R19 |
| Hazard warning lights (hazard lights) |
Standard equipment | Standard equipment | Standard equipment |
| Compression ratio | 12.7:1 | 12.7:1 | 12.7:1 |
| Reference price | 16842 USD | 15414 USD | 16842 USD |
| Engine | In-line twin-cylinder four-str oke, water-cooled·850cc |
In-line twin-cylinder four-str oke, water-cooled·850cc |
In-line twin-cylinder four-str oke, water-cooled·850cc |
| Engine stroke | Four-stroke | Four-stroke | Four-stroke |
| Number of engine cylinders | Twin cylinders | Twin cylinders | Twin cylinders |
| Engine structure | In-line | In-line | In-line |
| Transmission | International 6-speed | International 6-speed | International 6-speed |
| Transmission type | International 6-speed | International 6-speed | International 6-speed |
| Available colors | Metal Storm black | White | San Marino Blue |
| Rear brake system | 265mm single disc, single-pist on floating caliper |
265mm single disc, single-pist on floating caliper |
265mm single disc, single-pist on floating caliper |
| Rear suspension system | Central spring strut, hydrauli c adjustable spring preload, a djustable rebound damping |
Central spring strut, hydrauli c adjustable spring preload, a djustable rebound damping |
Central spring strut, hydrauli c adjustable spring preload, a djustable rebound damping |
| Rear swing arm | Cast aluminum | Cast aluminum | Cast aluminum |
| Rear light | LED | LED | LED |
| Rear wheel specification | 150/70-R17 | 150/70-R17 | 150/70-R17 |
| Brand | BMW | BMW | BMW |
| Official average fuel consumpt ion (L/100km) |
4.78 | 4.78 | 4.78 |
| Width (mm) | 850 | 850 | 850 |
| Seat height (mm) | 815 | 815 | 815 |
| Cornering ABS system (ABS PRO/ ABS EVO, etc.) |
Standard equipment | Standard equipment | Standard equipment |
| Trail (mm) | 104.5 | 104.5 | 104.5 |
| Displacement (cc) | 850 | 850 | 850 |
| Curb weight (kg) | 224 | 224 | 224 |
| Maximum power (kW) | 57 | 57 | 57 |
| Maximum power/speed (kW/rpm) | 57/6250 | 57/6250 | 57/6250 |
| Maximum power speed (rpm) | 6250 | 6250 | 6250 |
| Maximum torque (N·m) | 86 | 86 | 86 |
| Maximum torque/speed (N·m/rpm) | 86/6250 | 86/6250 | 86/6250 |
| Maximum torque speed (rpm) | 6250 | 6250 | 6250 |
| Maximum payload (kg) | 216 | 216 | 216 |
| Maximum horsepower (Ps) | 77.5 | 77.5 | 77.5 |
| Maximum horsepower (ps) | 77.5 | 77.5 | 77.5 |
| Maximum speed (km/h) | 190 | 190 | 190 |
| Mode selection | Rain mode, Road mode, Pro mode | Rain mode, Road mode | Rain mode, Road mode, Pro mode |
| Fuel tank capacity (L) | 15 | 15 | 15 |
| Throttle configuration | Electronic throttle | Electronic throttle | Electronic throttle |
| Slipper clutch | Standard equipment | Standard equipment | Standard equipment |
| Fuel type | Gasoline | Gasoline | Gasoline |
| Traction control system | Standard equipment | Standard equipment | Standard equipment |
| Clutch | Wet multi-plate slipper clutch | Wet multi-plate slipper clutch | Wet multi-plate slipper clutch |
| Exact displacement (cc) | 853 | 853 | 853 |
| Bore x stroke (mm) | 84x77 | 84x77 | 84x77 |
| Tire pressure monitoring | Standard equipment | - | Standard equipment |
| Model | Adventure | Adventure | Adventure |
| Frame type | Steel bridge frame | Steel bridge frame | Steel bridge frame |
| Turn signal | LED | LED | LED |
| Tire type | Vacuum tire | Vacuum tire | Vacuum tire |
| Rim | Aluminum alloy cast type | Aluminum alloy cast type | Aluminum alloy cast type |
| Wheelbase (mm) | 1559 | 1559 | 1559 |
| Intake form | Naturally aspirated | Naturally aspirated | Naturally aspirated |
| Valve train structure | DOHC four valves per cylinder | DOHC four valves per cylinder | DOHC four valves per cylinder |
| Length (mm) | 2255 | 2255 | 2255 |
| Height (mm) | 1225 | 1225 | 1225 |
